Bolts to the bellhousing.
PTT's Tri-MAX Hydraulic Release Bearing (HRB) is the most reliable, lightest, and strongest bolt-in HRB on the racecar market. Tri-MAX is designed to work with all small diameter multi-disc racing clutches and will fit Muncie, Jerico, Roltek, T-10, T-101, Saginaw & other transmissions. Tri-MAX has a full 3/4" of release travel, (the longest travel in its class) and has superbly engineered hydraulics to ensure positive, 100% clutch engagement. PTT's custom-designed, low drag, 1.6" radius face bearing is standard equipment. The smaller diameter contact reduces clutch pedal effort, while also lowering the thrust on the back of the crank! Tri-MAX works best with 5/8" or 3/4" master cylinders.
Tri-MAX is CNC manufactured to aircraft industry tolerances from high strength aluminum. All moving parts are premium hardcoat anodized for long, trouble-free life. All Tri-MAX bearings are pressure tested to twice normal operating pressure before leaving the factory. You can bolt a Tri-MAX in with confidence knowing that it will work as advertised right out of the box. The velvety smooth clutch actuation you get from a Tri-MAX must be felt to be believed. Tri-MAX is the reason you want to run a hydraulic release bearing.
- MAX-imum strength! Manufactured from high-strength extruded aluminum. Guaranteed for life never to break due to structural failure!
- MAX-imum lightness! Tri-MAX weighs less than 1 pound! That's 20% to 50% less than other manufacturers' bolt-in HRB's
- MAX-imum reliability! Built to withstand more than 3 times normal operating pressure.
- Tri-MAX has 3/4" of bearing travel.
- Simple bolt-in installation. No shims to adjust or complicated measuring.
- Precision aligned for less clutch wear
- Low-drag hydraulics guarantee complete clutch engagement
- Includes PTT's exclusive 1.6" diameter radius faced angular contact ball bearing
- Works best with 5/8” or 3/4” master cylinders. (the smaller master cylinder gives you lower pedal effort & better clutch control)
Click here for Hydraulic Release Bearing Catalog.
Tri-MAX Hydraulic Release Bearing Slave Cylinder
- Bolt-in Hydraulic Release Bearing (HRB) for small diameter racing clutches
- Fits a 3 disc clutch with a Chevy flywheel & flexplate
- Uses PTT’s proprietary 1.6” (40.6mm) diameter, radius face bearing
- Shortest possible height is: 70” (68.6mm) OAL, using a 1.65” (42mm) tall Piston
- Uses interchangeable, different length pistons (ordered separately) for height adjustability
- Has a 1.39” (35.3mm) through hole, for trans snout clearance
- Bolts into bellhousing. Bellhousing must be drilled for Tri-MAX pattern.
- With an external bleeder kit
- No hydraulic supply line is included
